Model CU-9-1500 is a 9:1 multi-core unun housed in a NEMA enclosure box (4″ x 4″ x 2″) with top stud/eyebolt output used to translate a 50 ohm input up to 450 ohms at RF power levels up to 1500 watts PEP when used with a matched load.
Great for end fed antennas - great for FT-8 and digital mode power ratings are approximately 30% of PEP ratings into a matched 450 ohm load. For non-resonant end fed antennas, you will need a feed line choke on the coax. See typical antenna configuration notes below for details.
Due to many requests for antenna static bleeders, we have developed a product line of static bleeders for coax and for ladder line applications. Static electricity is caused by many situations including high desert wind, atmospheric conditions, etc. You may hear static crashes or have a buildup of static electricity that my be annoying during a radio conversation and it may be harmful to solid state electronics if high voltages are present on the RF input to your equipment.
A static “Bleeder” which shorts the direct static voltage to ground while leaving the RF frequency voltage unaffected if very beneficial particularly to those operations in desert conditions where low humidity, high static buildup are quite common. The SB-1 and SB-2 coax static bleeders work on coax line and the SB-3 static bleeder is meant for ladder line.
THESE DEVICES ARE NOT FOR LIGHTNING PROTECTION AND PROVIDES NO PROTECTION FOR LIGHTNING STRIKES!!!!!
Model CU-9-1500 is a 9:1 multi-core unun housed in a NEMA enclosure box (4″ x 4″ x 2″) with top stud/eyebolt output used to translate a 50 ohm input up to 450 ohms at RF power levels up to 1500 watts PEP when used with a matched load.
Great for end fed antennas - great for FT-8 and digital mode power ratings are approximately 30% of PEP ratings into a matched 450 ohm load. For non-resonant end fed antennas, you will need a feed line choke on the coax. See typical antenna configuration notes below for details.
