Palstar LA-1K Linear Amplifier Deluxe RFI Kit - 7 Filters for RF In/Out, AC power, Control Lines
SKU RFI-PALSTAR-LA1K$99.95On SaleList price $129.95 Save 23%1Save this product for later Customer reviews Reviews only from verified customersNo reviews yet. You can buy this product and be the first to leave a review.Share this product with your friendsPalstar LA-1K Linear Amplifier Deluxe RFI Kit - 7 Filters for RF In/Out, AC power, Control LinesProduct DetailsMPN: RFI-PALSTAR-LA1KFilter Power Rating (PEP watts): max coax cable ratingRFI Suppression Range (MHz): 1-600 MHz# Ferrite Filters: 7Typical Use:: AC/DC power, RF In/out (x3), Control LinesAll coax I/O and control lines and AC/DC power line for high end amplifiers with multiple RF inputs and outputs, control/keying/frequency I/O.
Includes typical amps such as Yaesu Quadra, Icom PW1, ACOM, ALPHA,Tokyo High Power, Palstar, ETC.
Included are the following chokes and installation guidelines to suppress RFI in and out:
Deluxe Kit:
RF Input (1x):Ring Filter (1.4” ID) – 5-9 turns of RG-58/8X size through center
RF Output (3x):Snap On Filter (1” ID) – 3 turns of coax cable through center
Relay/ALC Cables (1x):Snap On Filter (3/4” ID) – multiple turns through center, both cables in same ferrite
Band Control cable:Snap On Filter (3/4” ID)- multiple turns through filter
AC/DC Power:Snap On Filter (1” ID) – 3 turns of power cord through center
You get 1.4" ID Ring x 1, 1" ID snap on x 4, 3/4" ID snap on x 2 with each kit.
STOP THE RFI NOW WITH THIS SIMPLE TO INSTALL KIT
Other cool productsRecently viewed products
HF 1-61 MHz coax feed line common mode chokes
Palstar LA-1K Linear Amplifier Deluxe RFI Kit - 7 Filters for RF In/Out, AC power, Control Lines
All coax I/O and control lines and AC/DC power line for high end amplifiers with multiple RF inputs and outputs, control/keying/frequency I/O.
Includes typical amps such as Yaesu Quadra, Icom PW1, ACOM, ALPHA,Tokyo High Power, Palstar, ETC.
Included are the following chokes and installation guidelines to suppress RFI in and out:
Deluxe Kit:
RF Input (1x):Ring Filter (1.4” ID) – 5-9 turns of RG-58/8X size through center
RF Output (3x):Snap On Filter (1” ID) – 3 turns of coax cable through center
Relay/ALC Cables (1x):Snap On Filter (3/4” ID) – multiple turns through center, both cables in same ferrite
Band Control cable:Snap On Filter (3/4” ID)- multiple turns through filter
AC/DC Power:Snap On Filter (1” ID) – 3 turns of power cord through center
You get 1.4" ID Ring x 1, 1" ID snap on x 4, 3/4" ID snap on x 2 with each kit.
STOP THE RFI NOW WITH THIS SIMPLE TO INSTALL KIT
1:1 feed line Chokes (also known as feed line current chokes, common mode chokes, line isolators, current mode chokes, and 1:1 baluns/ununs) are available in kit form or assembled form in a weatherproof Current Unun and Balun Enclosure which we call a CUBE™. All 1:1 chokes are ferrite based and are designed for 50 ohm coaxial cable input and 50 ohm output. 1:1 Ferrite toroidal or bead chokes have a higher choking impedance than our popular Sleeve Chokes and various models are available for specific frequency ranges and power levels.
1:1 Chokes are useful for choking common mode currents that may flow on the exterior of the coax cable shield while allowing the signals on the interior of the shield and the center conductor to flow unaffected and keeping the common mode current on the antenna. They isolate the coax shield and prevent it from becoming part of the antenna system.
1:1 Chokes are useful between balanced lines for center fed dipoles at their fundamental frequency (468/f (MHz), beam antennas with a 50 ohm balanced driven element, G5RV, loops, yagis, NVIS antennas, mobile installations, portable antennas and anywhere common mode current (or RFI) is a problem. They are also helpful between transmitter and linear amplifier or between linear amp and antenna tuner or as isolation chokes where higher choking impedance is needed (in the range of 2K-7K ohms).
1:1 Chokes are also very useful as feed line current chokes at the “radio end” of the antenna (we call them coax noise filters) where they choke/filter common mode current induced onto the coax shield from radiated waves (from your antenna, and other sources such as DSL routers, computer devices, plasma TVs, etc. originating in your house or your neighbor’s house). For RFI issues see RFI/EMI Solutions for general use or for specific radios and devices.
For best results we recommend a 1:1 choke at the “antenna end” of the coax and a coax noise filter at the “radio end” of the coax. (A side benefit is a reduction in noise level caused by common mode currents). 1:1 chokes are also available as Sleeve Chokes (Slip on or Snap on) for ease of installation and light weight on the antenna.
