40-6 Meter Loop Antenna System with 4:1 Balun and Choke Combo, (40, 20, 17, 15, 12, 11, 10, 6 meters) 500/1.5KW/5KW PEP Options

SKU PAL-LOOP4010-500
$169.95
On Sale
$189.95 Save 11%
PEP Power Rating Select
1
Save this product for later
Share this product with your friends
40-6 Meter Loop Antenna System with 4:1 Balun and Choke Combo, (40, 20, 17, 15, 12, 11, 10, 6 meters) 500/1.5KW/5KW PEP Options
Product Details
MPN: PAL4010LOOP-500, -1500, -5000
Country/Region of Manufacture: USA
Input ohms/Output ohms: 50 in/200 out
Frequency Range < 2:1 SWR (MHz): Balun rated at 1.8-61 MHz for 1.5KW, 1.8-31 MHz for 3KW/5KW
PEP Power Rating (watts): 500/1.5KW/5KW
Input Connector: SO-239
Output Connector(s): Eyebolts/Wing Nut
Hardware Type: Stainless Steel
Enclosure Size: 4"x4"x 2"(1.5KW), 4"x 4" x 4"(5KW)
Weight (pounds): 3#(500)/4#(1.5KW)/5#(5KW)

40-6 Meter Loop antenna (144' wire) + 500/1500/5000 Watt PEP rated 4:1 Current Balun + internal 1:1 Current Balun in one enclosure + 4 insulators for support

* Complete package - just add coax

* works multiple bands with ease

* can be configured as delta, square, rectangle or multi-sided horizontal loop (6 insulators included)

* Choice of 500, 1.5KW or 5KW PEP rated baluns to suit power needs

* No need for extra feed line choke as it is built into the 4:1 balun enclosure

After many requests we have created a compact, special balun for OCF and loop (Skyloop or Delta loop) antennas. The CB-4-1-1500/5000 is a CUBE enclosure containing a multi-core, broadband 4:1 impedance transformer in series with a 1:1 current balun for extra common mode current choking to keep RF current off the outside of the coax braid and on the antenna where it belongs. The extra choking action also means that the coax feed line will not act as a radiator causing unnecessary RF interference (RFI).

1.5KW Rated for full 1500 watts PEP and 1000 watts CW/FT8 (ICAS). 1.8Mhz – 61 MHz.

5KW Rated for full 5000 watts PEP and 1500 watts CW/FT8 (ICAS). 1.8Mhz – 61 MHz.

500 watt version is in "BULLET" format, 1.5KW is a 4 x 4 x 2 cube and 5KW is in 4" x 4" x 4" enclosure.
