SPE 1.3/1.5K-FA HF Linear Amplifier Deluxe RFI Kit - 17 Filters for RF In/Out, AC power, CAT/USB/ALC/PTT

In stock
Product Details
Filter Power Rating (PEP watts): max coax cable rating
RFI Suppression Range (MHz): 1-100 MHz
# Ferrite Filters: 12
Typical Use:: AC/DC power, RF In/out, Control Lines

All coax I/O and control lines and AC/DC power line for SPE-1.3K-FA or SPE-1.5K-FA amplifiers with multiple RF inputs and outputs, control/keying/frequency I/O.

Included are the following chokes and installation guidelines to suppress RFI in and out:

RF Input (3x):Ring Filter (1.4” ID) – 5-9 turns of RG-58/8X size through center

RF Output (4x):Snap On Filter (1” ID) – 3 turns of coax cable through center

Relay Cable/ALC Cable (4x):Snap On Filter (1/2” ID) – multiple turns through center

CAT/USB (5x):Snap On Filter (1/2” ID)- multiple turns through filter for each ACC

AC Power:Snap On Filter (1” ID) – 3 turns of power cord through center

You get 1.4" ID Ring x 3, 1" ID snap on x 5, 1/2" ID snap on x 9 with each kit.
